| LINA | 7007AW |
| STAN | Standard |
| ORDER | 7007AW | 制造商型号 |
| SD | 35mm | 内径 |
| D | 62mm | 外径 |
| B | 14mm | 宽度 |
| R | 1.0 mm | 最小倒角尺寸 |
| R1 | 0.60 mm | 最小倒角尺寸 |
| CR1 | 18300[N] | 基本额定动载荷 |
| COR1 | 13400[N] | 基本额定静载荷 |
| FO | 0.0 | Factors |
| LG | 9000[rpm] | 脂润滑极限转速 |
| LO | 13000[rpm] | 油润滑极限转速 |
| A | 21.0 mm | Eff. Load center |
| DA1 | 41.0 mm | Abutment and Fillet Dimensions min. |
| DA2 | 56.0 mm | Abutment and Fillet Dimensions max. |
| RA | 1.0 mm | Abutment and Fillet Dimensions max. |
| MASS | 0.153[kg] | 轴承质量 |
