| LINA | 16006 |
| STAN | 普通品 |
| ORDER | 16006 | 制造商型号 |
| SD | 30mm | 内径 |
| D | 55mm | 外径 |
| B | 9mm | 宽度 |
| R | 0.3 mm | 最小倒角尺寸 |
| CR1 | 11200[N] | 基本额定动载荷 |
| COR1 | 7350[N] | 基本额定静载荷 |
| FO | 15.2 | 计算系数 |
| LG | 13000[rpm] | 脂润滑极限转速 |
| LO | 15000[rpm] | 油润滑极限转速 |
| DAM1 | 32.0 mm | Abutment and Fillet Dimensions min. |
| DA1 | 0.0 mm | Abutment and Fillet Dimensions max. |
| DA2 | 53.0 mm | Abutment and Fillet Dimensions max. |
| RA | 0.3 mm | Abutment and Fillet Dimensions max. |
| MASS | 0.087[kg] | 轴承质量 |
