| LINA | 51108 |
| ORDER | 51108 | 制造商型号 |
| SD | 40mm | 内径 |
| D | 60mm | 外径 |
| T | 13mm | 宽度 |
| SR | 0.6 mm | Chamfer Dimension min. |
| CAN | 27100[N] | Basic Load Ratings |
| COAN | 63000[N] | Basic Load Ratings |
| CA | 2770[kgf] | Basic Load Ratings |
| COA | 6400[kgf] | Basic Load Ratings |
| GRE | 3600[min^-1] | Limiting Speeds (Grease) |
| OIL | 5300[min^-1] | Limiting Speeds (Oil) |
| SD1 | 60 mm | Outside Diameter |
| D1 | 42 mm | Outside Diameter |
| SDA | 52 mm | Abutment and Fillet Dimensions min. |
| DA | 48 mm | Abutment and Fillet Dimensions max. |
| SRA | 0.6 mm | Abutment and Fillet Dimensions max. |
| MASS | 0.120[kg] | 质量 |
