| LINA | 51208 |
| ORDER | 51208 | 制造商型号 |
| SD | 40mm | 内径 |
| D | 68mm | 外径 |
| T | 19mm | 宽度 |
| SR | 1.0 mm | Chamfer Dimension min. |
| CAN | 47500[N] | Basic Load Ratings |
| COAN | 98500[N] | Basic Load Ratings |
| CA | 4850[kgf] | Basic Load Ratings |
| COA | 10000[kgf] | Basic Load Ratings |
| GRE | 2800[min^-1] | Limiting Speeds (Grease) |
| OIL | 4300[min^-1] | Limiting Speeds (Oil) |
| SD1 | 68 mm | Outside Diameter |
| D1 | 42 mm | Outside Diameter |
| SDA | 57 mm | Abutment and Fillet Dimensions min. |
| DA | 51 mm | Abutment and Fillet Dimensions max. |
| SRA | 1.0 mm | Abutment and Fillet Dimensions max. |
| MASS | 0.270[kg] | 质量 |
