| LINA | 51214 |
| ORDER | 51214 | 制造商型号 |
| SD | 70mm | 内径 |
| D | 105mm | 外径 |
| T | 27mm | 宽度 |
| SR | 1.0 mm | Chamfer Dimension min. |
| CAN | 74000[N] | Basic Load Ratings |
| COAN | 189000[N] | Basic Load Ratings |
| CA | 7550[kgf] | Basic Load Ratings |
| COA | 19200[kgf] | Basic Load Ratings |
| GRE | 1900[min^-1] | Limiting Speeds (Grease) |
| OIL | 2800[min^-1] | Limiting Speeds (Oil) |
| SD1 | 105 mm | Outside Diameter |
| D1 | 72 mm | Outside Diameter |
| SDA | 91 mm | Abutment and Fillet Dimensions min. |
| DA | 84 mm | Abutment and Fillet Dimensions max. |
| SRA | 1.0 mm | Abutment and Fillet Dimensions max. |
| MASS | 0.793[kg] | 质量 |
