| LINA | 5204 |
| STAN | - | Standard |
| ORDER | 5204 | 制造商型号 |
| SD | 20mm | 内径 |
| D | 47mm | 外径 |
| B | 20.6mm | 宽度 |
| R | 1.0 mm | 最小倒角尺寸 |
| CR1 | 19600[N] | 基本额定动载荷 |
| COR1 | 12400[N] | 基本额定静载荷 |
| CR2 | 2000[kgf] | 基本额定动载荷 |
| COR2 | 1270[kgf] | 基本额定静载荷 |
| LG | 10000[rpm] | 脂润滑极限转速 |
| LO | 13000[rpm] | 油润滑极限转速 |
| AO | 24.3 mm | Load center spacings |
| DA1 | 26 mm | Abutment and Fillet Dimensions min. |
| DA2 | 41 mm | Abutment and Fillet Dimensions max. |
| RA | 1.0 mm | Abutment and Fillet Dimensions max. |
| MASS | 0.12[kg] | 轴承质量 |
