| LINA | 7903CTYN |
| STAN | Standard |
| ORDER | 7903CTYN | Bearing No. |
| SD | 17[mm] | Inside Diameter |
| D | 30[mm] | Outside iameter |
| B | 7[mm] | Width |
| R | 0.3[mm] | Chamfer Dimension |
| R1 | 0.15[mm] | Chamfer Dimension |
| CR1 | 5000[N] | Basic Dynamic Load Ratings |
| COR1 | 2940[N] | Basic Static Load Ratings |
| FO | 14.8 | Factors |
| LG | 34000[rpm] | Limiting Speed Grease |
| LO | 48000[rpm] | Limiting Speed Oil |
| A | 6.6[mm] | Eff. Load center |
| DA1 | 19.5[mm] | Abutment and Fillet Dimensions min. |
| DA2 | 27.5[mm] | Abutment and Fillet Dimensions max. |
| RA | 0.3[mm] | Abutment and Fillet Dimensions max. |
| MASS | 0.017[kg] | Mass |
