单列，单列/万能配对。
NSK
恩斯克
| LINA | 7204CTYN |
| STAN | Standard |
| ORDER | 7204CTYN | Bearing No. |
| SD | 20[mm] | Inside Diameter |
| D | 47[mm] | Outside iameter |
| B | 14[mm] | Width |
| R | 1.0[mm] | Chamfer Dimension |
| R1 | 0.60[mm] | Chamfer Dimension |
| CR1 | 14600[N] | Basic Dynamic Load Ratings |
| COR1 | 8050[N] | Basic Static Load Ratings |
| FO | 13.3 | Factors |
| LG | 24000[rpm] | Limiting Speed Grease |
| LO | 34000[rpm] | Limiting Speed Oil |
| A | 11.5[mm] | Eff. Load center |
| DA1 | 26.0[mm] | Abutment and Fillet Dimensions min. |
| DA2 | 41.0[mm] | Abutment and Fillet Dimensions max. |
| RA | 1.0[mm] | Abutment and Fillet Dimensions max. |
| MASS | 0.118[kg] | 质量 |
